Programmable GNSS Amplified Splitter GA30-PV4

√ Frequency Range: 1150~1650MHz； √ Military Grade: working temp. -55°~85°(the working temp. of core device: -55°~125°)； √ Adjustable Gain Range: 0~30dB, 1dB step adjustable； √ Output Voltage at IN port: 5V； √ Programmed Control Methods: 485 protocol connector； √ 100% localization of the whole machine； √ Power Supply Method: √ 220VAC to 12VDC power adapter power supply（standardized）； √ Dual 18~76V DC input (optional)； √ Optional Connectors: N/TNC/BNC/SMA (Female)

Classification:

Product

GPS and GNSS Amplifiers

产品配件:

GA30-PV4_en(1).pdf

Programmable GNSS Amplified Splitter GA30-PV4

GA30-PV4_en(1).pdf

File size: 387.3KB

Select all

Description
Videos
Download
BUY NOW

Military grade working temperature -55°-85°(core device operating temperature: -55*~125)
Adjustable gain range: 0-30dB, Stepping: 1dB
Operating frequency range:1150MHZ ~1650MHz
Output voltage at IN: 5V；
Connector mode: TNC-K,N,SMA
Program control mode: 485 protocol interface.
Power supply mode.
220VAC to 12vDC power adapter power supply; (Standard)
Dual 18-76V DC inputs;(Optional)
Input port votage: 5V DC

Descriptions：

GA30-V4 Amplfied splter is a device that integrates an acive GNNS amplfier wth one input and four portoutputs. The signal received by the active GPS receivingantemna is evenly distributed to 4 outputs and suplied to other receiving devices. In such an appication, its lN terminal can be configured to pass 5V DC to powerthe acive GPS antenna connected to the port, and the other output ports wil have a 200 0hm Dc load to simulate the DC oss of any receiver antemna connected tothese ports. and the device can control the reauired gain and atenuation value through the 485 protocol. The maximum adjustable qain is 30dB.

Surface treatment process
Standard: nickel plating.
Options: copper plating, baking paint (conformal paint, gray)

Ordering Information

GA30-PV4-SF
SF: SMA Female
SFL: SMA Female with auto locked
NF: N Female
TF: TNC Female

Electrical parameters

Parameters	Condictions	Min	Std.	Max	Unit
Working temperature		-55		85	℃
Frequency Range	Ant to any ports	1150		1650	MHz
Input & output impedance	Input, All Output Ports		50		Ω
Range of Gain	1dB step		30		dB
Input VSWR			2.0:1
Output VSWT			2.0:1
Noise Figure			2	3	dB
Blance of Gain				2	dB
Isolation			20		dB
DC input	220VAC to 12VDC adaptor		12		VDC
Current			20		mA
Max input RF	Without demage			0	dBm
Interface		N Female、TNC Female、SMA Female
Number of input		1
Number of outputs		4
